266DDHESSA2A1E1L1C1H3 | ABB Differential Pressure Transmitter | Original ABB Transmitter

Part Number: 266DDHESSA2A1E1L1C1H3

  • Free Selection Free Online Product Selection Service

To pick up today

  • Fast Shipping & Competitive pricing

Our courier will deliver to the specified address

  • warranty Min. order: 1 piece & 2-Year Warranty

DHL courier will deliver to the specified address

Payment Methods:

Description

Product Number: 266DDHESSA2A1E1L1C1H3

Model: 266DDH Differential Pressure Transmitter
Manufacturer: ABB


Ordering Information
  • Base Model: 266DDH – Differential Pressure Transmitter with direct mount seal – BASE ACCURACY 0.06%
  • Sensor – Span Limits: E – 0.8 and 16 kPa; 8 and 160 mbar; 3.2 and 64 inH2O
  • Use code: S
  • Diaphragm Material/Fill Fluid (wetted parts): S – AISI 316 L ss; Silicone oil; NACE
  • Process flanges/adapters material and connection (wetted parts): A – AISI 316 L ss (Horizontal connection); 1/4 – 18 NPT-f direct; NACE¹
  • Bolts/Gasket (wetted parts): 2 – AISI 316 ss; PTFE¹ ²
  • Housing material and electrical connection: A – Aluminium alloy (barrel version); 1/2 ? 14 NPT
  • Output/Additional options: 1 – HART digital communication and 4 to 20 mA; Options requested by ‘Additional ordering code’³
  • Hazardous area certifications: E1 – ATEX Intrinsic Safety II 1 G and II 1/2 G Ex ia IIC T6; II 1 D Ex iaD 20 T 95°C and II 1/2D Ex iaD 21 T95°C
  • Integral LCD: L1 – Digital LCD integral display
  • Certificates (up to 2 different selections allowed): C1 – Inspection certificate EN 10204?3.1 of calibration (9-point)
  • Material traceability: H3 – Inspection certificate EN 10204?3.1 of process wetted parts
  1. Not available with low side diaphragm code R, 2, W
  2. Suitable for oxygen service
  3. Not available with Housing code G, Z, W.
  • Estimated Lead Time: 4 – 6 Weeks
  • Shipping Weight: 10 Kg
