Fisher A11 High Performance Butterfly Valve | Fisher Valve | Fisher Actuator

The Fisher A11 High Performance Butterfly Valve from JCSC MRO delivers unmatched durability and precise flow control at competitive prices, with fast global shipping and dedicated technical support to keep your operations running smoothly.

  • Free Selection Free Online Product Selection Service

To pick up today

  • Fast Shipping & Competitive pricing

Our courier will deliver to the specified address

  • warranty Min. order: 1 piece & 2-Year Warranty

DHL courier will deliver to the specified address

Payment Methods:

Description

Product Description

The Fisher A11 valve is a reliable, high performance Butterfly valve for both throttling and on/off applications. Available in either a wafer or single-flange design, it maintains tight shutoff, and can be specified for a wide range of pressure and temperature conditions, including cryogenic applications.

Specifications

Specifications Details
Certifications PED, CRN, Fugitive Emission, NACE, ATEX, CUTR, Fire Safe
Critical Service General Service
Flow Characteristics Linear
Material Carbon Steel, Stainless, Alloy
Operating Temperature Standard Temperature, High Temperature, Cryogenic
Power Source Electric, Hydraulic, Pneumatic, Electro-Hydraulic
Pressure Class ASME
Process Connection Type Flanged, Single Flanged, Double Flanged, Lugged, Wafer
Seat / Seal Type Metal, Soft
Shutoff Class Class IV (FCI 70-2), Class V (FCI 70-2), Class VI (FCI 70-2)
Standards B16.34
Stem Live Loaded, Adjustable Packing
Valve Size NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 12, NPS 14, NPS 16, NPS 18, NPS 20, NPS 24, NPS 30, NPS 36, Custom inlet/outlet, Up to NPS 72
Valve Size Standard NPS
Other Configurations Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.

Features

  • Choose from square, keyed, or splined shaft connections.
  • The pressure-assisted seal design provides tight shutoff.
  • Trim and bolting materials are available for applications involving sour liquids and gases.
  • The valve body self-centers on the line flange bolts as a fast, accurate means of centering the valve in the pipeline.
  • Seal retainer screws are located so there is no interference with the sealing function of either flat sheet or spiral-wound line flange gaskets.
  • A feature of the valve design is that the torque necessary to open and close the valve is the same, regardless of the direction in which the differential pressure is applied.
  • Interchangeability of all parts, including shafts and disks, simplifies service and reduces maintenance costs.

The Fisher A11 High Performance Butterfly Valve delivers exceptional reliability in demanding industrial applications, combining robust construction with precision engineering to minimize downtime. At JCSC MRO, we offer competitive pricing without compromising quality, ensuring you get superior valves at cost-effective rates. With streamlined logistics, we guarantee fast delivery to keep your projects on schedule, backed by responsive after-sales support to address any technical needs promptly. Trust JCSC MRO for valves that perform—and service that exceeds expectations.
