The Baumann 24000SB control valve is designed for low-flow, high-pressure industrial control applications, offering precise flow regulation with an ultra-low Cv rating (as low as 0.00013), making it ideal for injection processes. It provides versatile end connections, including threaded (standard), butt weld, and flanged options, ensuring compatibility with various piping systems. While the standard material is S31600/S31603 stainless steel, the valve is also available in special high-nickel alloys for enhanced durability in demanding environments. This combination of precision, high-pressure capability, and material flexibility makes the 24000SB a reliable choice for critical control applications.
| Specifications | Details |
|---|---|
| Certifications | PED, CU-TR, ATEX, CRN |
| Critical Service | Low Flow |
| Flow Characteristics | Equal Percentage, Linear |
| Material | Stainless, Alloy |
| Operating Temperature | Cryogenic, Standard Temperature, High Temperature |
| Pressure Class | ANSI CL150, ANSI CL300, ANSI CL600, ANSI CL900, ANSI CL1500 |
| Process Connection Type | Flanged, Butt Weld, Threaded |
| Shutoff Class | Class IV (FCI 70-2), Class VI (FCI 70-2) |
| Valve Size | NPS 1/2, NPS 3/4, NPS 1 |
| Valve Size Standard | NPS |
| Other Configurations | Contact your local Emerson sales office to learn about additional specifications or options for this product. |
Featuring a compact and lightweight design, this control valve significantly reduces piping installation costs while maintaining excellent performance.
The innovative dual plug and stem guiding system ensures exceptional stability during plug movement, delivering precise control even in demanding conditions
Offers multiple trim options with Cv ratings as low as 0.00013, providing flexibility to adapt to varying process requirements
Available with extended bonnet for extreme temperature applications ranging from -195°C to 537°C (-320°F to 1000°F)
The actuator features epoxy powder coating with stainless steel fasteners, combining aesthetic appeal with superior corrosion resistance
Multi-spring actuator supports field-reversible adjustment with minimal deadband, enabling direct response to remote control signals
Optional Fisher ENVIRO-SEAL enhanced packing system meets the most stringent emission control standards for environmentally responsible operation
Compatible with Fisher FIELDVUE digital valve controllers for remote calibration and diagnostics, greatly simplifying maintenance procedures
The Fisher Baumann 24000SB Bar Stock Control Valve delivers precision-engineered reliability for demanding low-flow applications, combining Fisher’s industry-leading quality with competitive pricing from GUAGEMART. Our streamlined logistics ensure fast delivery to keep your projects on schedule, backed by responsive after-sales support and technical expertise—because your operational efficiency is our priority. Trust GUAGEMART to provide not just products, but solutions that balance performance, value, and peace of mind.
