Micro Motion T-Series Straight Tube Coriolis Meter | DN25 | 316L Stainless Steel | T100T Sensor with 3700 Transmitter

The Micro Motion T-Series Straight Tube Coriolis Meter, integrating the T100T sensor and 3700 transmitter, delivers high-precision measurements of mass, density, and volume flow. Its titanium construction and 32 Ra surface finish ensure compatibility with various fluids while meeting hygienic standards. The 3700 transmitter offers flexible configuration options and real-time monitoring capabilities, optimizing customers’ production processes. By choosing our T-Series, you will receive exceptional performance and quality service support.

  • Free Selection Free Online Product Selection Service

To pick up today

  • Fast Shipping & Competitive pricing

Our courier will deliver to the specified address

  • warranty Min. order: 1 piece & 2-Year Warranty

DHL courier will deliver to the specified address

Payment Methods:

Description

Micro Motion T100T Coriolis Meter 1 Inch (DN25), Titanium Grade 9, 32 Ra Finish
Mass Flow Accuracy (Liquid) ±0.15% of rate
Mass Flow Repeatability (Liquid) ±0.05% of rate
Volume Flow Accuracy (Liquid) ±0.25% of rate
Volume Flow Repeatability (Liquid) ±0.05% of rate
Mass Flow Accuracy (Gas) ±0.50% of rate
Mass Flow Repeatability (Gas) ±0.05% of rate
Density Accuracy (Liquid) ±0.002 g/cm3 (±2.0 kg/m3)
Density Repeatability (Liquid) ±0.0005 g/cm3 (±0.5 kg/m3)
Temperature Accuracy ±1 °C ±0.5% of reading
Max Working Pressure 1,450 psig (100 barg)
Certifications UL, CSA, ATEX, ASME, 3-A, USDA, EHEDG
Micro Motion 3700 Controller and Transmitter Remote Field-Mount
Output Variables Mass & volume flow, net product content/flow, temperature, density, concentration
Local Display Multi-line LCD panel, backlit, 128 × 128 pixels
Power (AC Option) 85 to 265 VAC, 50/60 Hz, 30 VA
Power (DC Option) 18 to 30 VDC, 18 watts typical, 25 watts maximum
Input/Output Signals Two active 4–20 mA, three discrete outputs, one frequency output/input
Mounting Options Remote field-mount
Application Types Batch controller, custody transfer, two-phase flow, meter verification
Hazardous Approvals UL, CSA, ATEX, NEPSI
