STD730-E1AS1CS-1-C-AHS-12C-B-00A0-00-0000 | Honeywell STD700 | HoneyWell Pressure Transmitter

Part Number: STD730-E1AS1CS-1-C-AHS-12C-B-00A0-00-0000

  • Free Selection Free Online Product Selection Service

To pick up today

  • Fast Shipping & Competitive pricing

Our courier will deliver to the specified address

  • warranty Min. order: 1 piece & 2-Year Warranty

DHL courier will deliver to the specified address

Payment Methods:

Description

Part Number: STD730-E1AS1CS-1-C-AHS-12C-B-00A0-00-0000

Model: STD700 Differential Pressure Transmitter
Brand: Honeywell
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months

Ordering Information

Model STD730 Differential Pressure Transmitter
Process Wetted Heads & Diaphragm Materials E Process Head Material: 316 Stainless Steel
Diaphragm Material: 316 Stainless Steel
Fill Fluid 1 Silicone Oil 200
Process Connection A None
None (1/4′ NPTF female thread Std)
Bolt/Materials S 316 SS
Vent/Drain Type/Location 1 Head Type: Single Ended
Vent Type: None
Location: None
Vent Material: None
Gasket Material C Graphite
Static Pressure S Standard Static Pressure – 4500 psig (315 bar)
Head/Connect Orientation 1 Standard, High Side Left, Low Side Right(1) / Std Head Orientation
Approvals C ATEX Explosion proof, Intrinsically Safe & Non-incendive
Electronic Housing Material & Connection Type A Material: Polyester Powder Coated Aluminum
Connection: 1/2 NPT
Lighting Protection: None
Output/Protocol H Analog Output: 4-20mA dc
Digital Protocol: HART Protocol
Customer Interface Selections S
Application Software 1 Diagnostics: Standard Diagnostics
Output Limit, Failsafe & Write Protect Settings 2 Write Protect: Disabled
Fail Mode: Low< 3.6mAdc
High & Low Output Limits:(1) Honeywell Std (3.8 – 20.8 mAdc)
General Configuration C Custom Configuration (Unit Data Required from customer)
Accuracy and Calibration B Accuracy: Standard
Calibrated Range: Custom (Unit Data Required)
Calibration Qty: Single Calibration
Mounting Bracket 0 Bracket Type: None
Material: None
Customer Tag 0 No customer tag
Unassembled Conduit Plugs & Adapters A0 No Conduit Plugs or Adapters Required
Certifications & Warranty 00 None – No additional options
Factory 0000 Factory Identification
  1. Left side/Right side as viewed from the customer connection perspective
  • Estimated Lead Time: 12 – 16 Weeks
  • Shipping Weight: 8 Kg
