STD820-E1AS4AS-1-C-CHE-11C-B-21A6-F1-0000 | Honeywell STD820 | HoneyWell Pressure Transmitter

Part Number: STD820-E1AS4AS-1-C-CHE-11C-B-21A6-F1-0000

  • Free Selection Free Online Product Selection Service

To pick up today

  • Fast Shipping & Competitive pricing

Our courier will deliver to the specified address

  • warranty Min. order: 1 piece & 2-Year Warranty

DHL courier will deliver to the specified address

Payment Methods:

Description

Part Number: STD820-E1AS4AS-1-C-CHE-11C-B-21A6-F1-0000

Model: STD820 SmartLine Differential Pressure Transmitter
Brand: Honeywell
Condition: New & Original in Factory Packing
Factory Warranty: 12 Months

Ordering Information

Model STD820 Differential Pressure Transmitter
Process Wetted Heads & Diaphragm Materials E Process Head Material: 316 Stainless Steel
Diaphragm Material: 316L Stainless Steel
Fill Fluid 1 Silicone Oil 200
Process Connection A None
None (1/4′ NPTF female thread Std)
Bolt/Nuts Materials S 316 SS
Vent/Drain Type/Location 4 Head Type: Dual Ended
Vent Type: Standard Vent
Location: End
Vent Material: Matches Head Material(1)
Gasket Materials A Teflon® or PTFE (Glass Filled)
Static Pressure S Standard Static Pressure – 4500 psig (315 bar)
Head/Connect Orientation 1 Standard
High Side Left, Low Side Right(2) / Std Head Orientation
Approvals C ATEX Explosion proof, Intrinsically Safe & Non-incendive
Electronic Housing Material & Connection Type C Material: Polyester Powder Coated Aluminum
Connection: 1/2 NPT
Lighting Protection: Yes
Output/Protocol H Analog Output: 4-20mA dc
Digital Protocol: HART Protocol
Customer Interface Selections E Indicator: Advanced
Ext Zero, Span & Config Buttons: Yes
Languages: EN, GR, FR, IT,SP, RU, TU
Application Software 1 Diagnostics: Standard Diagnostics
Output Limit, Failsafe & Write Protect Settings 1 Write Protect: Disabled
Fail Mode: High> 21.0mAdc
High & Low Output Limits(3): Honeywell Std           (3.8 – 20.8 mAdc)
General Configuration C Custom Configuration (Unit Data Required from customer)
Accuracy and Calibration B Accuracy: Standard
Calibrated Range: Custom (Unit Data Required)
Calibration Qty: Single Calibration
Mounting Bracket 2 Bracket Type: Angle Bracket
Material: 304 SS
Customer Tag 1 One Wired Stainless Steel Tag (Up to 4 lines 26 char/line)
Unassembled Conduit Plugs & Adapters A6 1/2 NPT 316 SS Certified Conduit Plug
Certifications &
Warranty		 F1 Calibration Test Report & Certificate of Conformance (F3399)
Factory 0000 Factory Identification
  1. Except Carbon Steel Heads shall use 316SS Vent/Drain, Plugs & Adapters when required
  2. Left side/Right side as viewed from the customer connection perspective
  3. NAMUR Output Limits 3.8 – 20.5mAdc can be configured by the customer or select custom configuration Table Vc
  • Estimated Lead Time: 12 – 16 Weeks
  • Shipping Weight: 8 Kg
