Part Number: YokoGawa AXG050G-GA000BA1AL112B-1JA11/CH
| Model | AXG050G | Magnetic Flowmeter |
| Use | -G | General-purpose |
| Construction | A | Integral flowmeter |
| Explosion Protection | 000 | Non Explosion Protection Approval |
| Process Connection | BA1 | Stainless Steel Flange (F304) ASME Class 150 Flange |
| Lining | A | PFA Lining |
| Electrode | L | Stainless Steel 316L |
| Grounding Device | 1 | None |
| Housing and Coating | 1 | Standard Material with Standard Coating |
| Cable Entry | 2 | ASME 1/2 NPT Female |
| Accuracy | B | Standard |
| Power Supply | -1 | 100-240 V AC / 100-120 V DC |
| Communication and I/O | JA | #: A, B, C, D, E, F, G, H, J, K, P, Q, R, S, T HART 7 and I/O (Type A to K, P to T). |
| Transmitter Wiring Terminal | 1 | M4 Screw-type |
| Display | 1 | M4 Screw-type |
| /CH |
